Galvanized Iron Wire

Electric Galvanized Iron Wire Technical Information: Processing with low carbon steel wire, through drawing and electric galvanizing

Standard wire gauge for electro galvanized iron wire: from 8# to 16#
Electric galvanized iron wire uses: Electric galvanized wire is used in weaving of wire mesh, fencing for expressway and construction.

Hot-Dip Galvanized Iron Wire Technical Information: Material: super carbon steel Processing by drawing, hot-dip zinc coating

Hot-dip galvanized iron wire standard wire gauge: from 8# to 24#
Hot-dip galvanized wire property: Thick zinc-coating layer of hot-dipped galvanized iron wire offers super corrosion resistance with firm coating layer. Custom size available.




Galvanized wire, steel wire, annealed wire
wire gauge size SWG(mm) BWG(mm) metric(mm)
8 4.06 4.19 4.00
9 3.66 3.76 -
10 3.25 3.40 3.50
11 2.95 3.05 3.00
12 2.64 2.77 2.80
13 2.34 2.41 2.50
14 2.03 2.11 -
15 1.83 1.83 1.80
16 1.63 1.65 1.65
17 1.42 1.47 1.40
18 1.22 1.25 1.20
19 1.02 1.07 1.00
20 0.91 0.89 0.90
21 0.81 0.813 0.80
22 0.71 0.711 0.70
